SML151003 15-inch 100-Core Midbass Driver
Neodymium 97 magnetism 15-inch 100-Core Midbass Driver
Neodymium 97 magnetism 15-inch 100-Core Midbass Driver
SML151003 15-inch 100-Core Midbass Driver Specification:
Model | SML151003 |
Description | 15-inch 100-core midbass speaker |
Installation aperture | About 355mm |
Diagonal screw hole | About 368mm |
Outer Diameter | About 389mm |
Height | About 155mm |
Magnet material | Neodymium 97 magnetism |
Voice coil | 100-core Cupric Aluminum Flat Wire |
Cone paper | Import JBL paper basin |
Frame material | Cast aluminum frame |
Rated Impedance | 8 ohm |
DC Impedance | 6 ohm |
Rated Power | 600 Watts |
Maximum power | 1.2K Watts |
Sensitivity | 98 dB/1W/1m |
Frequency range | 30-2.5K Hz |
Resonant frequency | 40Hz |
Electrical Quality Factor Number | 0.3 |
Mechanical Quality Factor Value | 7.22 |
Total Quality Factor Number | 0.29 |
Effective Volume | 143 liters |
Vibration Area | 887 cm2 |
Magnetic Force | 23.3 Txm |
Effective Mobile Quality | 106g |
Place of Origin | Guangzhou, China |
Net Weight | About 6KG (No packaging) |
