SC127510 12 inches 75-core Coaxial Horn
Imported edged paper basin 12 inches 75-core Coaxial Horn
Imported edged paper basin 12 inches 75-core Coaxial Horn
SC127510 12 inches 75-core Coaxial Horn Specification:
Model | SC127510 |
Description | 12 inches 75-core Coaxial Horn |
Installation aperture | About 283mm |
Outer diameter | About 317mm |
Diagonal screw hole | About 304mm |
Height | About 150mm |
Magnet | High 85 magnetism, low 131 magnetism |
Voice Coil | High 44 core, low 75 core |
Drum paper | Imported edged paper basin |
Frame material | Cast aluminum frame |
Rated Impedance | 8 ohm |
Minimum Impedance | 6 ohm |
AES Rated Power | Treble 50 Watts /bass 350 Watts |
Maximum power | Treble 100 Watts /bass 700 Watts |
Sensitivity | Treble 99 dB /bass 107dB (1W/1m) |
Frequency range | 45-18K Hz |
Resonant frequency | 42Hz |
Electrical Quality Factor Number | 0.2 |
Mechanical Quality Factor Value | 8 |
Total Quality Factor Number | 0.19 |
Effective Volume | 120 liters |
Vibration Area | 480cm2 |
Magnetic Force | 18.6Txm |
Effective Mobile Quality | 48g |
Place of Origin | Guangzhou, China |
Net Weight | About 4.6KG (No packaging) |
SC127510 12 inches 75-core Coaxial Horn Features:
1. Rich sense of hierarchy and permeability
The physical structure of coaxial loudspeaker is to design the tweeter and bass loudspeaker in the same speaker skillfully according to the law of sound expression.
2. True professional edged paper basin
The basin edge made of natural cloth edge can prevent deformity and fatigue and make the sound more deep and wide, clearer and pure, and true restored sound quality。
3. Pursuing sound quality, professional loudspeaker brand
Outdoor coaxial horn, human voice reproduction, surging power has a stronger sense of presence, create immersive music enjoyment.
