SP-SWT89 T Series All In One Smartboard

Physical Size

89 inch

Effective Size

80 inch

Display Ratio

16:10

Physical Dimension

1967*1107*90mm

Packing Size

2045*1310*90mm

Net Weight

22 KG

Gross Weight

27 KG

Induction Technology

Infrared

Induction Object

Finger, pen or untransparent object

Resolution

32768(W) * 32768(D)

Calibration Deviation

<2mm

Tracking Speed

>200inch/sec

Cursor Speed

Max 300dots/sec

Effective Touch Object

>=∅8mm

Mouse Function

Single click, double click, right click

Responding Speed

15ms

Consequent RS

8ms

Life

100000hrs

Voltage

DC 5.0V +- 5%

Touchscreen Power Supply

USB

Power Consumption

<=1W(200mA DC 5V)

CPU

Pentium 800 ( 1G Hz (X86) CPU or above )

Memory

1GB or above

Hard disk

>=800mb

Operation System

Windows, Linux, Mac, Android

Working Temperature

30℃ ~ 60℃

Working Humidity

0% ~ 95%

Working Environment

Indoor / Outdoor

Power Input

100-240V

Consumption

<=5W

PC Voltage

4.1~5.5V

CPU

i3, i5, i7

Motherboard

H61/H81/H110

Hard Disc

500G HDD/128SSD, Higher configuration can be customized.

Wireless Mic

2.4G

Mic Function

Laser Pointer, VOL, PPT

Speaker

2*15W

Visualizer

5M

Scan Size

A4

Power

100-240V

Control Mode

One Key Control

Control Code

99 units integrated

Data Display

Digital Screen

System Boot

ID Card Control

Hot Key

Set card control, freeze time, control code and system lock.

Control Panel

Mute*1, Digital locker*1, Reboot*1, VOL*2,Signal switch*1,Power*1

Connection Ports

USB*6, VGA IN*1, VGA OUT*1, MIC*1, AC IN*1, AC OUT*2, RJ45*2, RS-232*1, AUDIO IN*1, AUDIO OUT*1, HDMI*1

Packing Details

All in one Smartboard *1; Software Disc *1; Whiteboard PEN *2; User Manual *1; Warranty Card *1; 5M USB *1; Wall-mount Suit *1

Place of Origin

Guangzhou, China
