PA Power Amplifier, 120W-250W-350W-450W-550W-650W
SP-PA120, SP-PA250, SP-PA350, SP-PA450, SP-PA550, SP-PA650
Description:
This range of power amplifiers are designed for commercial and industrial public address applications.
Rack mount design in 2U type, rated power from 120W, 250W, 350W, 450W, 550W to 650W, which provide a wide selection to meet different sizes sound system needs.
Both RCA and XLR inputs and output make it selectable for installer, balanced line output feeds to another power amplifier as well as secures the signal transmission is less noise and longer distance.
70V, 100V and 4-16ohm speaker outputs are convenient for installation when selection different speaker matching.
A master volume control is included.
Complete protection includes clip, short circuit, high temp and overload. Indicators for power, signal, clip, protection and temperature.
Feature:
▪ Rack mount PA 100V amplifier in 2U type
▪ Industrial design for audio project, long term & stable use
▪ Rated power from 120W, 250W, 350W, 450W, 550W to 650W
▪ 70V-100V and 4-16Ω flexible speaker outputs
▪ Balanced XLR type line input and unbalanced RCA phone jack line input
▪ Balanced XLR type line output feeds to another power amplifier
▪ Reliable protection of over heat, over load, clip & short circuit
▪ 4 LED indicators for signal and protection
▪ Built-in automatic temperature controlled fan cooling
▪ Double-sided PCB board, SMT production process
▪ Strong power output, Strong load capacity
▪ Warranty of 3 years with CE certificate
Specification:
Model | SP-PA120 | SP-PA250 | SP-PA350 | SP-PA450 | SP-PA550 | SP-PA650 |
Description | PA System Power Amplifier |
Rated Power Output | 120W | 250W | 350W | 450W | 550W | 650W |
Speaker Output | 100V, 70V & 4-16 Ohms |
Input | RCA: 10k ohms(Ω) < 1V ; XLR: 0.775V (0 dB) |
Output | RCA: 10k ohms(Ω) < 1V ; XLR: 0.775V (0 dB) |
Frequency Response | 50Hz~18KHz (±3dB) |
S/N Ratio | >96 dB |
THD | Less than 0.5% at 1KHz, 100V -3dB |
Cooling System | Automatic two-speed temperature controlled Fan |
Protection | FUSE 3.15A | FUSE 6.3A | FUSE 8A | FUSE 10A | FUSE 12A | FUSE 12A |
Clip, short-circuit, overload and high temp protection |
Power Supply | AC 110-220V/50-60Hz |
Power Consumption | 180W | 375W | 525W | 675W | 825W | 1050W |
Power Cord | (3 x 0.75mm²) x 1.5M (standard) |
Finishing | 2U panel in black color Case: steel plate, black, elegant appearance |
Net Weight | 11 KG | 13.5 KG | 14.5 KG | 15.5 KG | 16.5 KG | 17.8 KG |
Product Dimension | 88(H)×485(W)×340(D)mm |
Rear Panel:
