Product Description:
▪ Power: 3*20W@8Ω
▪ Amplifier Channel: 4 Channel, RMS 4x15W amplifier board
▪ Amplifier Type: Digital Class D
▪ Frequency Response: 120Hz-15KHz(±3dB)
▪ THD: <0.05% at 1kHz,1/3 rated power
▪ S/N: >70 dB
▪ Speaker Unit: 6"*1
▪ Installation: In-ceiling
▪ Material: ABS enclosure,metal clamps
▪ Power Supply: DC15V5A
▪ Dimension: Φ188*76mm
▪ Cutting Hole: Φ170mm
Specification:
Model Number | BT613 |
Type | Active |
Use | HOME THEATRE |
Channels | 2 (2.0) |
Place of Origin | China |
| Guangdong |
Power | 3*20W@8 Ohm |
Amplifier Channel | 4 Channel, RMS 4x15W amplifier board |
Amplifier Type | Digital Class D |
Frequency Response | 120Hz-15KHz(±3dB) |
THD | <0.05% at 1kHz,1/3 rated power |
S/N | >70 dB |
Speaker Unit | 6"*1 |
Material | ABS enclosure,metal clamps |
Power Supply | DC15V5A |
Cutting Hole | d170mm |






High Definition Pictures:
Brochure/Data Sheet:
SURPASSCeilingSpeakerSP-BT613.pdf、
Operation Manual:
