SC127528 12 inches 75-core Coaxial Horn
Imported 7DF paper basin 12 inches 75-core Coaxial Speaker
Imported 7DF paper basin 12 inches 75-core Coaxial Speaker
SC127528 12 inches 75-core Coaxial Horn Specification:
Model | SC127528 |
Description | 12 inches 75-core Coaxial Speaker |
Installation aperture | About 283mm |
Outer diameter | About 316mm |
Diagonal screw hole | About 303mm |
Height | About 162mm |
Magnet | High 138 magnetism, low 138 magnetism |
Voice Coil | High 75 core, low 75 core |
Drum paper | Imported 7DF paper basin |
Frame material | Cast aluminum frame |
Rated Impedance | 8 ohm |
Minimum Impedance | 6 ohm |
AES Rated Power | Treble 80 Watts /bass 350 Watts |
Maximum power | Treble 160 Watts /bass 700 Watts |
Sensitivity | Treble 97 dB /bass 104dB (1W/1m) |
Frequency range | 57-18K Hz |
Resonant frequency | 48Hz |
Electrical Quality Factor Number | 0.21 |
Mechanical Quality Factor Value | 11.2 |
Total Quality Factor Number | 0.2 |
Effective Volume | 95 liters |
Vibration Area | 540cm2 |
Magnetic Force | 21.5Txm |
Effective Mobile Quality | 55g |
Place of Origin | Guangzhou, China |
Net Weight | About 5.2KG (No packaging) |
SC127528 12 inches 75-core Coaxial Horn Features:
1. Out of the voice is exceptionally clear
The design of coaxial integration can easily obtain good sound effect, sound field positioning effect and clear hierarchical sense.
2. From R&D to material selection to every work
Put the high and low softness into the water as a stone, and emit the high and low sound waves from one point, so as to recognize clearly and not interfere with the pure nature of the sound.
3. Pursuing sound quality, professional loudspeaker brand
Outdoor coaxial horn, human voice reproduction, surging power has a stronger sense of presence, create immersive music enjoyment.
