Product Description:
4 Gang Zigbee Switch and 4 Scene Button Specification:
Networking Methods: MESH
Power Supply Method: LIVE and Neutral Wire
Material: PC+ Alumina
Voltage: 100-250V 50/60Hz
Current: 10A Max
Max Load: 500W/Gang
Power Consumption: <0.5W
Working Temperature: 0℃~40℃
Communication Frequency: 2.4G
Communication Protocols: Zigbee
Switch Indicator: white when on
Certification: FCC, CE, RoHS
APP: Tuya Smart/Smart Life
Specification:
Brand Name | SURPASS |
Model Number | PW420TS |
Max. Current | 10A |
Max. Voltage | 250V |
Power Supply Method | LIVE and Neutral Wire |
Networking Methods | MESH |
Resolution | 480x480 |
Processor | 4-core processor CORTEX A7 |
Material | PC+ Alumina |
Voltage | 100-250V 50/60Hz |
Current | 10A Max |
Max Load | 500W/Gang |
Power Consumption | <0.5W |
Working Temperature | 0℃~40℃ |
High Definition Pictures:
Brochure/Data Sheet:
SURPASSWallAmplifierSP-PW420TS.pdf、
Operation Manual:
